SHL coal-fired hot water boiler

  • thermal capacity: 7-28MW
  • Rated thermal efficiency: ≥80%
  • Pressure: 1.6MPa
  • Available fuel: Coal
  • Available industries:

Product introduction

The basic structure of SHL series bulk chain grate biomass boiler is composed of upper drum, lower drum, water wall, convection tube bundle, economizer, air preheater and other components. The front part of the boiler is composed of water-cooled walls, and the front and rear water-cooled walls form the front and rear water-cooled arches.

A convection tube bundle is arranged between the upper and lower drums. The tube bundle is equipped with transverse partitions to allow the flue gas to flow laterally. An economizer and air preheater are arranged at the rear of the boiler.

The SHL boiler grate adopts a double-layer or single-layer structure to better meet the actual needs of users. The soot blower interface is reserved at the convection tube bundle of the boiler and the heating surface of the economizer, and necessary measures can be taken for special fuels (especially those with strong cohesion) to prevent problems before they occur.





Production advantage:

1. The boiler adopts the structure of anti-coke collector box, which is located on both sides of the grate and is directly in contact with the burning material layer. As the main heat-absorbing surface at the bottom of the furnace, the purpose is to absorb some heat, adjust the temperature of the fuel layer, prevent coking, and cool the coking slag, which is not bonded to the side wall.

2. Water cooling device (More than 10 ton boiler) is arranged at the coal gate of the boiler to reduce the temperature here and prevent burnt the coal gate. The combustion of the boiler is more stable.3. Compact structure, compared with the same type of boiler, small size, saving boiler room infrastructure investment.

3. Runs steadily and convenient adjustment.

4. The high efficiency and energy saving furnace arch of heat resistant concrete is adopted in the furnace, which improves the fuel ignition condition, adopts independent air chamber, achieves reasonable air distribution, and forms an air power field favorable to combustion in the furnace, thus enlarging the adaptability of fuel.

5. The smoke window at the outlet of the boiler arch has a certain dedusting effect.




Technical parameter

Model YLL-700SCⅡ/AⅡ YLL-1000SCⅡ/AⅡ YLL-1200SCⅡ/AⅡ YLL-1400SCⅡ/AⅡ YLL-1800SCⅡ/AⅡ YLL-2400SCⅡ/AⅡ
Rated thermal power(KW) 700 1000 1200 1400 1800 2400

Thermal efficiency(%)

85 85 85 85 85 85

Design pressure(MPa)

1.1 1.1 1.1 1.3 1.3 1.3
Work pressure(MPa) 0.8 0.8 0.8 1 1 1
Max working temperature(℃) 320 320 320 320 320 320
Furnace content oil volume(m³/h) 0.6 0.8 1 1.2 1.6 2.1
Circulating oil volume(m³/h) 60 100 100 100 100 160
Piping connection caliber(DN) 100 125 125 125 150 150
Appearance size L(mm) 4830 4830 5300 5650 5650 6000
W(mm) 2500 2500 2620 2650 2700 2700
H(mm) 5500 5500 5700 6000 6400 6400
Reference weight(t) 17.5 18 19 20 22 25
